TERRIA trailed machines cover a wide range of applications in soil cultivation. Perfect ground tracking is a prerequisite for working at the same depth across the whole working width, every square metre of soil is valuable. Fully versatile to meet the highest expectations.

TERRIA trailed machines cover a wide range of applications in soil cultivation. Perfect ground tracking is a prerequisite for working at the same depth across the whole working width, every square metre of soil is valuable. Fully versatile to meet the highest expectations.




Technology

Technical data

 TERRIA 4040TERRIA 5040TERRIA 6040
Working width13'1'' (4 m)16'5'' (5 m)19'8'' (6 m)
Tines13 pcs.17 pcs.21 pcs.
Spacing1' (310 mm)0'11'' (290 mm)0'11'' (290 mm)
Row spacing2'7'' (800 mm)2'7'' (800 mm)2'7'' (800 mm)
Concave discs8 pcs.10 pcs.12 pcs.
Beam dimensions0'4'' x 0'4'' (100 x 100 mm)0'4'' x 0'4'' (100 x 100 mm)0'4'' x 0'4'' (100 x 100 mm)
Under frame clearance2'8'' (820 mm)2'8'' (820 mm)2'8'' (820 mm)
Triggering pressure of stone protection system1323 lbs (600 kg)1323 lbs (600 kg)1323 lbs (600 kg)
Power requirement200 hp250 hp300 hp
Transport length30'2'' (9,2 m)30'2'' (9,2 m)30'2'' (9,2 m)
Transport width9'10'' (3 m)9'10'' (3 m)9'10'' (3 m)
TERRIA 4040
Working width13'1'' (4 m)
Tines13 pcs.
Spacing1' (310 mm)
Row spacing2'7'' (800 mm)
Concave discs8 pcs.
Beam dimensions0'4'' x 0'4'' (100 x 100 mm)
Under frame clearance2'8'' (820 mm)
Triggering pressure of stone protection system1323 lbs (600 kg)
Power requirement200 hp
Transport length30'2'' (9,2 m)
Transport width9'10'' (3 m)
TERRIA 5040
Working width16'5'' (5 m)
Tines17 pcs.
Spacing0'11'' (290 mm)
Row spacing2'7'' (800 mm)
Concave discs10 pcs.
Beam dimensions0'4'' x 0'4'' (100 x 100 mm)
Under frame clearance2'8'' (820 mm)
Triggering pressure of stone protection system1323 lbs (600 kg)
Power requirement250 hp
Transport length30'2'' (9,2 m)
Transport width9'10'' (3 m)
TERRIA 6040
Working width19'8'' (6 m)
Tines21 pcs.
Spacing0'11'' (290 mm)
Row spacing2'7'' (800 mm)
Concave discs12 pcs.
Beam dimensions0'4'' x 0'4'' (100 x 100 mm)
Under frame clearance2'8'' (820 mm)
Triggering pressure of stone protection system1323 lbs (600 kg)
Power requirement300 hp
Transport length30'2'' (9,2 m)
Transport width9'10'' (3 m)
