Clean forage wherever you go

Our NOVACAT T trailed mowers with a working width of 3.04 m / 3.46 m are ideal for mowing with small tractors. On the trailed version with chassis, you do not need any lifting power, so you can also use lower power tractors. This helps you save fuel.

Clean forage wherever you go

Our NOVACAT T trailed mowers with a working width of 3.04 m / 3.46 m are ideal for mowing with small tractors. On the trailed version with chassis, you do not need any lifting power, so you can also use lower power tractors. This helps you save fuel.




Technology

Technical data

 NOVACAT 307 T EDNOVACAT 307 T RCNOVACAT 3007 T EDNOVACAT 3007 T RCNOVACAT 3507 T ED
MountingSemi-mounted Semi-mounted Semi-mounted Semi-mounted Semi-mounted
DrawbarSide-pull drawbar Side-pull drawbar center-pull drawbar center-pull drawbar center-pull drawbar
Weight4389 lbs (1991 kg)4522 lbs (2051 kg)4698 lbs (2131 kg)4828 lbs (2190 kg)4863 lbs (2206 kg)
Working width10' (3,04 m)10' (3,04 m)10' (3,04 m)10' (3,04 m)11'4'' (3,46 m)
Transport width9'10'' (3 m)9'10'' (3 m)9'10'' (3 m)9'10'' (3 m)11'3'' (3,42 m)
Transport height6'10'' (2,08 m)6'10'' (2,08 m)6'10'' (2,08 m)6'10'' (2,08 m)6'10'' (2,08 m)
Transport length20' (6,1 m)20' (6,1 m)24'10'' (7,56 m)24'10'' (7,56 m)24'10'' (7,56 m)
Conditioner width6'11'' (2,12 m)6'11'' (2,12 m)6'11'' (2,12 m)-8'4'' (2,54 m)
PTO speed1000 rpm1000 rpm1000 rpm1000 rpm1000 rpm
Mower discs7 pcs.7 pcs.7 pcs.7 pcs.8 pcs.
Mower blades14 pcs.14 pcs.14 pcs.14 pcs.16 pcs.
Power requirement75 hp75 hp75 hp75 hp85 hp
Coverage3,6 ha/h3,6 ha/h3,6 ha/h3,6 ha/h4,2 ha/h
Wear skids5 pcs.5 pcs.5 pcs.5 pcs.6 pcs.
High-cut skids5 pcs.5 pcs.5 pcs.5 pcs.6 pcs.
High-cut skids inside / outside1 pcs.1 pcs.1 pcs.1 pcs.1 pcs.
Tires - chassis340/55-16 340/55-16 340/55-16 340/55-16 340/55-16
Swath width with conditioner min6'3'' (1,9 m)5'7'' (1,7 m)6'3'' (1,9 m)5'7'' (1,7 m)7'3'' (2,2 m)
Swath width with conditioner max8'10'' (2,7 m)8'2'' (2,5 m)8'10'' (2,7 m)8'2'' (2,5 m)10'2'' (3,1 m)
 NOVACAT 3507 T RCNOVACAT 3507 T ED COLLECTORNOVACAT 3507 T RC COLLECTOR
MountingSemi-mounted Semi-mounted Semi-mounted
Drawbarcenter-pull drawbar center-pull drawbar center-pull drawbar
Weight5040 lbs (2286 kg)6228 lbs (2825 kg)6371 lbs (2890 kg)
Working width11'4'' (3,46 m)11'4'' (3,46 m)11'4'' (3,46 m)
Transport width11'3'' (3,42 m)11'3'' (3,42 m)11'3'' (3,42 m)
Transport height6'10'' (2,08 m)6'10'' (2,08 m)6'10'' (2,08 m)
Transport length24'10'' (7,56 m)28'3'' (8,6 m)28'3'' (8,6 m)
Conditioner width-8'4'' (2,54 m)-
PTO speed1000 rpm1000 rpm1000 rpm
Mower discs8 pcs.8 pcs.8 pcs.
Mower blades16 pcs.16 pcs.16 pcs.
Power requirement85 hp85 hp85 hp
Coverage4,2 ha/h4,2 ha/h4,2 ha/h
Wear skids6 pcs.6 pcs.6 pcs.
High-cut skids6 pcs.6 pcs.6 pcs.
High-cut skids inside / outside1 pcs.1 pcs.1 pcs.
Tires - chassis340/55-16 340/55-16 340/55-16
Swath width with conditioner min7'3'' (2,2 m)--
Swath width with conditioner max9'10'' (3 m)--
NOVACAT 307 T ED
MountingSemi-mounted
DrawbarSide-pull drawbar
Weight4389 lbs (1991 kg)
Working width10' (3,04 m)
Transport width9'10'' (3 m)
Transport height6'10'' (2,08 m)
Transport length20' (6,1 m)
Conditioner width6'11'' (2,12 m)
PTO speed1000 rpm
Mower discs7 pcs.
Mower blades14 pcs.
Power requirement75 hp
Coverage3,6 ha/h
Wear skids5 pcs.
High-cut skids5 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min6'3'' (1,9 m)
Swath width with conditioner max8'10'' (2,7 m)
NOVACAT 307 T RC
MountingSemi-mounted
DrawbarSide-pull drawbar
Weight4522 lbs (2051 kg)
Working width10' (3,04 m)
Transport width9'10'' (3 m)
Transport height6'10'' (2,08 m)
Transport length20' (6,1 m)
Conditioner width6'11'' (2,12 m)
PTO speed1000 rpm
Mower discs7 pcs.
Mower blades14 pcs.
Power requirement75 hp
Coverage3,6 ha/h
Wear skids5 pcs.
High-cut skids5 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min5'7'' (1,7 m)
Swath width with conditioner max8'2'' (2,5 m)
NOVACAT 3007 T ED
MountingSemi-mounted
Drawbarcenter-pull drawbar
Weight4698 lbs (2131 kg)
Working width10' (3,04 m)
Transport width9'10'' (3 m)
Transport height6'10'' (2,08 m)
Transport length24'10'' (7,56 m)
Conditioner width6'11'' (2,12 m)
PTO speed1000 rpm
Mower discs7 pcs.
Mower blades14 pcs.
Power requirement75 hp
Coverage3,6 ha/h
Wear skids5 pcs.
High-cut skids5 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min6'3'' (1,9 m)
Swath width with conditioner max8'10'' (2,7 m)
NOVACAT 3007 T RC
MountingSemi-mounted
Drawbarcenter-pull drawbar
Weight4828 lbs (2190 kg)
Working width10' (3,04 m)
Transport width9'10'' (3 m)
Transport height6'10'' (2,08 m)
Transport length24'10'' (7,56 m)
Conditioner width-
PTO speed1000 rpm
Mower discs7 pcs.
Mower blades14 pcs.
Power requirement75 hp
Coverage3,6 ha/h
Wear skids5 pcs.
High-cut skids5 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min5'7'' (1,7 m)
Swath width with conditioner max8'2'' (2,5 m)
NOVACAT 3507 T ED
MountingSemi-mounted
Drawbarcenter-pull drawbar
Weight4863 lbs (2206 kg)
Working width11'4'' (3,46 m)
Transport width11'3'' (3,42 m)
Transport height6'10'' (2,08 m)
Transport length24'10'' (7,56 m)
Conditioner width8'4'' (2,54 m)
PTO speed1000 rpm
Mower discs8 pcs.
Mower blades16 pcs.
Power requirement85 hp
Coverage4,2 ha/h
Wear skids6 pcs.
High-cut skids6 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min7'3'' (2,2 m)
Swath width with conditioner max10'2'' (3,1 m)
NOVACAT 3507 T RC
MountingSemi-mounted
Drawbarcenter-pull drawbar
Weight5040 lbs (2286 kg)
Working width11'4'' (3,46 m)
Transport width11'3'' (3,42 m)
Transport height6'10'' (2,08 m)
Transport length24'10'' (7,56 m)
Conditioner width-
PTO speed1000 rpm
Mower discs8 pcs.
Mower blades16 pcs.
Power requirement85 hp
Coverage4,2 ha/h
Wear skids6 pcs.
High-cut skids6 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min7'3'' (2,2 m)
Swath width with conditioner max9'10'' (3 m)
NOVACAT 3507 T ED COLLECTOR
MountingSemi-mounted
Drawbarcenter-pull drawbar
Weight6228 lbs (2825 kg)
Working width11'4'' (3,46 m)
Transport width11'3'' (3,42 m)
Transport height6'10'' (2,08 m)
Transport length28'3'' (8,6 m)
Conditioner width8'4'' (2,54 m)
PTO speed1000 rpm
Mower discs8 pcs.
Mower blades16 pcs.
Power requirement85 hp
Coverage4,2 ha/h
Wear skids6 pcs.
High-cut skids6 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min-
Swath width with conditioner max-
NOVACAT 3507 T RC COLLECTOR
MountingSemi-mounted
Drawbarcenter-pull drawbar
Weight6371 lbs (2890 kg)
Working width11'4'' (3,46 m)
Transport width11'3'' (3,42 m)
Transport height6'10'' (2,08 m)
Transport length28'3'' (8,6 m)
Conditioner width-
PTO speed1000 rpm
Mower discs8 pcs.
Mower blades16 pcs.
Power requirement85 hp
Coverage4,2 ha/h
Wear skids6 pcs.
High-cut skids6 pcs.
High-cut skids inside / outside1 pcs.
Tires - chassis340/55-16
Swath width with conditioner min-
Swath width with conditioner max-


Machine Advisor

HAYTOOL ASSIST


Match your tedder to the working width of your mower to get the highest utilisation and best work quality from your machines.
The best spreading quality is achieved when the tedder completely covers the swath of mowed grass on each pass. And ideally, the tractor should drive along a forage-free lane. The forage then remains loose on top of the grass stubble, making it an easy target for the tines.
HAYTOOL ASSIST helps you quickly and easily find the right tedder for your mower.




www.mypoettinger.com/haytool-assist




MyPÖTTINGER

MyPÖTTINGER


  • Get valuable information and tips on all PÖTTINGER machines
  • Specific information on your PÖTTINGER machines in "My Machines".
  • Instruction manuals, spare parts lists, maintenance information, as well as all technical details available online
  • Machine-specific documentation for all PÖTTINGER machines built from 1997 onwards available online

www.mypoettinger.com


Medien

Image gallery

Qualität


Qualität

Quality

We manufacture our products using the very latest flexible industrial methods in several locations. Everything we do is delivered to the highest possible quality.
Here, we test our products as to their suitability in field conditions in order to pass on only the very best to our customers. The testing centre is one of the most modern in agriculture worldwide and has an excellent reputation. Many other internationally-recognised manufacturers have their products tested here.
Our customers expect our machines to operate faultlessly and be completely reliable. To achieve this, we apply the highest quality standards applicable to the manufacture of agricultural machines - our own. The whole production process is monitored by our internal quality management team.
Our coating processes involve the most environmentally-friendly painting methods. Powder-coated paintwork has proven to be flexible and durable in the field. This ensures that our machines retain their value even after years of hard service.
