AEROSEM A Pneumatic implement-mounted seed drills



Single-disc coulters and DUAL DISC double-disc coulters are available for planting cereals. PCS integrates precision seed drilling technology into a pneumatic seed drill, making you independent from single seed drills. This means greater flexibility and more cost efficient operation.

Video abspielen Videos Prospekte Brochures

Single-disc coulters and DUAL DISC double-disc coulters are available for planting cereals. PCS integrates precision seed drilling technology into a pneumatic seed drill, making you independent from single seed drills. This means greater flexibility and more cost efficient operation.

Customer benefits



Technology

Technology

Technical data

 AEROSEM 300AEROSEM 400AEROSEM 3000AEROSEM 3002 ADDAEROSEM 3502 ADD
Working width--9'10.11'' (3 m)9'10.11'' (3 m)11'5.79'' (3,5 m)
Seed hopper volume370 gal (1400 l)-370 gal (1400 l)330 gal (1250 l)330 gal (1250 l)
Row spacing4.92'' (12,5 cm)4.92'' (12,5 cm)4.92'' (12,5 cm)5.91''
4.92'' (15
12,5 cm)		4.92'' (12,5 cm)
Coulter pressure (Maximum)37 lbs (17 kg)37 lbs (17 kg)37 lbs (17 kg)110 lbs (50 kg)110 lbs (50 kg)
Transport width--9'10.11'' (3 m)9'10.11'' (3 m)11'5.79'' (3,5 m)
Filling height seed hopper-----
Number of rows--24 pcs.20
24 pcs.		28 pcs.
Coulter spacing (Front to rear)1'1.78'' (35 cm)1'1.78'' (35 cm)1'1.78'' (35 cm)11.81'' (30 cm)11.81'' (30 cm)
Oil flowrate for fan drive---9 gal (35 l)9 gal (35 l)
Oil flowrate for PCS drive---7 gal (25 l)7 gal (25 l)
Weight with disc shares--1543 lbs (700 kg)--
Weight with DualDisc---2811 lbs (1275 kg)3153 lbs (1430 kg)
 AEROSEM 4000AEROSEM 4002 ADDAEROSEM 4500AEROSEM 6000
Working width13'1.48'' (4 m)13'1.48'' (4 m)14'9.16'' (4,5 m)19'8.22'' (6 m)
Seed hopper volume370 gal (1400 l)330 gal (1250 l)370 gal (1400 l)370 gal (1400 l)
Row spacing4.92'' (12,5 cm)5.91''
4.92'' (15
12,5 cm)		4.92'' (12,5 cm)5.91'' (15 cm)
Coulter pressure (Maximum)37 lbs (17 kg)110 lbs (50 kg)37 lbs (17 kg)37 lbs (17 kg)
Transport width13'1.48'' (4 m)13'1.48'' (4 m)14'9.16'' (4,5 m)19'8.22'' (6 m)
Filling height seed hopper----
Number of rows32 pcs.26
32 pcs.		26 pcs.40 pcs.
Coulter spacing (Front to rear)1'1.78'' (35 cm)11.81'' (30 cm)1'1.78'' (35 cm)1'1.78'' (35 cm)
Oil flowrate for fan drive-9 gal (35 l)--
Oil flowrate for PCS drive-7 gal (25 l)--
Weight with disc shares1786 lbs (810 kg)--2183 lbs (990 kg)
Weight with DualDisc-3554 lbs (1612 kg)--
AEROSEM 300
Working width-
Seed hopper volume370 gal (1400 l)
Row spacing4.92'' (12,5 cm)
Coulter pressure (Maximum)37 lbs (17 kg)
Transport width-
Filling height seed hopper-
Number of rows-
Coulter spacing (Front to rear)1'1.78'' (35 cm)
Oil flowrate for fan drive-
Oil flowrate for PCS drive-
Weight with disc shares-
Weight with DualDisc-
AEROSEM 400
Working width-
Seed hopper volume-
Row spacing4.92'' (12,5 cm)
Coulter pressure (Maximum)37 lbs (17 kg)
Transport width-
Filling height seed hopper-
Number of rows-
Coulter spacing (Front to rear)1'1.78'' (35 cm)
Oil flowrate for fan drive-
Oil flowrate for PCS drive-
Weight with disc shares-
Weight with DualDisc-
AEROSEM 3000
Working width9'10.11'' (3 m)
Seed hopper volume370 gal (1400 l)
Row spacing4.92'' (12,5 cm)
Coulter pressure (Maximum)37 lbs (17 kg)
Transport width9'10.11'' (3 m)
Filling height seed hopper-
Number of rows24 pcs.
Coulter spacing (Front to rear)1'1.78'' (35 cm)
Oil flowrate for fan drive-
Oil flowrate for PCS drive-
Weight with disc shares1543 lbs (700 kg)
Weight with DualDisc-
AEROSEM 3002 ADD
Working width9'10.11'' (3 m)
Seed hopper volume330 gal (1250 l)
Row spacing5.91''
4.92'' (15
12,5 cm)
Coulter pressure (Maximum)110 lbs (50 kg)
Transport width9'10.11'' (3 m)
Filling height seed hopper-
Number of rows20
24 pcs.
Coulter spacing (Front to rear)11.81'' (30 cm)
Oil flowrate for fan drive9 gal (35 l)
Oil flowrate for PCS drive7 gal (25 l)
Weight with disc shares-
Weight with DualDisc2811 lbs (1275 kg)
AEROSEM 3502 ADD
Working width11'5.79'' (3,5 m)
Seed hopper volume330 gal (1250 l)
Row spacing4.92'' (12,5 cm)
Coulter pressure (Maximum)110 lbs (50 kg)
Transport width11'5.79'' (3,5 m)
Filling height seed hopper-
Number of rows28 pcs.
Coulter spacing (Front to rear)11.81'' (30 cm)
Oil flowrate for fan drive9 gal (35 l)
Oil flowrate for PCS drive7 gal (25 l)
Weight with disc shares-
Weight with DualDisc3153 lbs (1430 kg)
AEROSEM 4000
Working width13'1.48'' (4 m)
Seed hopper volume370 gal (1400 l)
Row spacing4.92'' (12,5 cm)
Coulter pressure (Maximum)37 lbs (17 kg)
Transport width13'1.48'' (4 m)
Filling height seed hopper-
Number of rows32 pcs.
Coulter spacing (Front to rear)1'1.78'' (35 cm)
Oil flowrate for fan drive-
Oil flowrate for PCS drive-
Weight with disc shares1786 lbs (810 kg)
Weight with DualDisc-
AEROSEM 4002 ADD
Working width13'1.48'' (4 m)
Seed hopper volume330 gal (1250 l)
Row spacing5.91''
4.92'' (15
12,5 cm)
Coulter pressure (Maximum)110 lbs (50 kg)
Transport width13'1.48'' (4 m)
Filling height seed hopper-
Number of rows26
32 pcs.
Coulter spacing (Front to rear)11.81'' (30 cm)
Oil flowrate for fan drive9 gal (35 l)
Oil flowrate for PCS drive7 gal (25 l)
Weight with disc shares-
Weight with DualDisc3554 lbs (1612 kg)
AEROSEM 4500
Working width14'9.16'' (4,5 m)
Seed hopper volume370 gal (1400 l)
Row spacing4.92'' (12,5 cm)
Coulter pressure (Maximum)37 lbs (17 kg)
Transport width14'9.16'' (4,5 m)
Filling height seed hopper-
Number of rows26 pcs.
Coulter spacing (Front to rear)1'1.78'' (35 cm)
Oil flowrate for fan drive-
Oil flowrate for PCS drive-
Weight with disc shares-
Weight with DualDisc-
AEROSEM 6000
Working width19'8.22'' (6 m)
Seed hopper volume370 gal (1400 l)
Row spacing5.91'' (15 cm)
Coulter pressure (Maximum)37 lbs (17 kg)
Transport width19'8.22'' (6 m)
Filling height seed hopper-
Number of rows40 pcs.
Coulter spacing (Front to rear)1'1.78'' (35 cm)
Oil flowrate for fan drive-
Oil flowrate for PCS drive-
Weight with disc shares2183 lbs (990 kg)
Weight with DualDisc-
 AEROSEM 3002 AAEROSEM 3502 AAEROSEM 4002 A
Working width9'10.11'' (3 m)11'5.79'' (3,5 m)13'1.48'' (4 m)
Seed hopper volume330 gal (1250 l)330 gal (1250 l)330 gal (1250 l)
Row spacing5.91''
4.92'' (15
12,5 cm)		4.92'' (12,5 cm)5.91''
4.92'' (15
12,5 cm)
Coulter pressure (Maximum)55 lbs (25 kg)55 lbs (25 kg)55 lbs (25 kg)
Transport width9'10.11'' (3 m)11'5.79'' (3,5 m)13'1.48'' (4 m)
Filling height seed hopper6'5.16'' (196 cm)6'5.16'' (196 cm)6'5.16'' (196 cm)
Number of rows20
24 pcs.		28 pcs.26
32 pcs.
Coulter spacing Single disc coulter11.81'' (30 cm)11.81'' (30 cm)11.81'' (30 cm)
Oil flowrate for fan drive9 gal (35 l)9 gal (35 l)9 gal (35 l)
Weight with disc shares2385 lbs (1082 kg)2732 lbs (1239 kg)2937 lbs (1332 kg)
AEROSEM 3002 A
Working width9'10.11'' (3 m)
Seed hopper volume330 gal (1250 l)
Row spacing5.91''
4.92'' (15
12,5 cm)
Coulter pressure (Maximum)55 lbs (25 kg)
Transport width9'10.11'' (3 m)
Filling height seed hopper6'5.16'' (196 cm)
Number of rows20
24 pcs.
Coulter spacing Single disc coulter11.81'' (30 cm)
Oil flowrate for fan drive9 gal (35 l)
Weight with disc shares2385 lbs (1082 kg)
AEROSEM 3502 A
Working width11'5.79'' (3,5 m)
Seed hopper volume330 gal (1250 l)
Row spacing4.92'' (12,5 cm)
Coulter pressure (Maximum)55 lbs (25 kg)
Transport width11'5.79'' (3,5 m)
Filling height seed hopper6'5.16'' (196 cm)
Number of rows28 pcs.
Coulter spacing Single disc coulter11.81'' (30 cm)
Oil flowrate for fan drive9 gal (35 l)
Weight with disc shares2732 lbs (1239 kg)
AEROSEM 4002 A
Working width13'1.48'' (4 m)
Seed hopper volume330 gal (1250 l)
Row spacing5.91''
4.92'' (15
12,5 cm)
Coulter pressure (Maximum)55 lbs (25 kg)
Transport width13'1.48'' (4 m)
Filling height seed hopper6'5.16'' (196 cm)
Number of rows26
32 pcs.
Coulter spacing Single disc coulter11.81'' (30 cm)
Oil flowrate for fan drive9 gal (35 l)
Weight with disc shares2937 lbs (1332 kg)


Machine Advisor

METERING WHEEL ASSIST


Choose the right metering wheel for your seed material simply by using METERING WHEEL ASSIST on your smartphone, tablet or PC. Get the new app from the App Store now (for iOS operating systems).



To the METERING WHEEL ASSIST app: https://www.poettinger.at/metering-wheel-assist/

To the iOS app: https://itunes.apple.com/de/app/p%C3%B6tsem/id1434048370?mt=8




TRAMLINE ASSIST


To set up the optimal tramline system, you need to synchronise your machinery. TRAMLINE ASSIST helps you to do this. When choosing your seed drill, parameters such as the working width of your crop care machines, track and tyre widths are critical for optimising tramlining. TRAMLINE ASSIST identifies the tramline rhythm for you, the position of the tramline rows, and the number of rows that need to be switched off.


www.mypoettinger.com/tramline-assist

MY POETTINGER

MyPÖTTINGER


  • Get valuable information and tips on all PÖTTINGER machines
  • Specific information on your PÖTTINGER machines in "My Machines".
  • Instruction manuals, spare parts lists, maintenance information, as well as all technical details available online
  • Machine-specific documentation for all PÖTTINGER machines built from 1997 onwards available online
